apache-auth

Frontend for a transparent cookie-based authentication layer for arbitrary Apache vhosts

Overview

apache-auth is a simple Express/React application that serves as a frontend for accepting and destroying client-side session authentication cookies distributed and validated server-side using Apache's mod_auth_form module. Together with mod_auth_form, apache-auth behaves as a full framework for an elegant, fully transparent and stack-agnostic SSO implementation for any web application.

This project attempts to be a simple solution to auth-walling any virtual host: unlike more complex SSO implementations that require explicit integration with your application logic for authentication, apache-auth sits transparently between the client and underlying application in the virtual host configuration.

The goal of this project is to provide a simple and straightforward implementation of SSO to auth-wall arbitrary applications against an existing .htpasswd user directory.

Architecture

I use a dedicated domain auth.kevinlin.info for SSO authentication requests. Requests to any domain on *.kevinlin.info secured under apache-auth are validated server-side for a session cookie. If the cookie is valid and present, the request continues uninterrupted; if not, the user is 302 redirected to auth.kevinlin.info where he or she will receive a Set-Cookie header from mod_auth_form, storing a client-side session cookie. Further requests to auth-walled domains will continue transparently until the user destroys the cookie (via a logout) or the cookie reaches its expiry time.

Sample configuration and usage

First, the necessary modules need to be enabled. mod_session_crypto can be optionally enabled to make use of the SessionCryptoPassphrase directive for encrypted client-side cookies.

$ sudo a2enmod session
$ sudo a2enmod session_crypto
$ sudo a2enmod auth_form

Making use of this application involves setting up the configuration for the virtual host running the authentication site (in my case, auth.kevinlin.info), and configuration for any virtual host that should be protected with authentication.

For example, if apache-auth is running locally on port 18800:

<VirtualHost *:80>
    ServerName auth.kevinlin.info
    Redirect permanent / https://auth.kevinlin.info/
</VirtualHost>

<VirtualHost *:443>
    ServerName auth.kevinlin.info

    <Location "/error">
        Deny from all
        ProxyPass !
    </Location>

    <Location "/auth-login">
        SetHandler form-login-handler
        AuthFormLoginRequiredLocation "https://auth.kevinlin.info/error"
        AuthFormProvider file
        AuthUserFile "/etc/apache2/.htpasswd"
        AuthType form
        AuthName "SSO"

        Session On
        SessionCookieName session path=/;domain=.kevinlin.info;httponly;secure
        SessionCryptoPassphrase ${APACHE_SESSION_PASSPHRASE}
        SessionMaxAge 86400

        Require valid-user

        ProxyPass !
    </Location>

    <Location "/auth-logout">
        SetHandler form-logout-handler
        AuthName "SSO"

        Session On
        SessionCookieName session path=/;domain=.kevinlin.info;httponly;secure
        SessionCryptoPassphrase ${APACHE_SESSION_PASSPHRASE}
        SessionMaxAge 86400

        ProxyPass !
    </Location>

    ProxyRequests Off
    ProxyPreserveHost On
    ProxyPass / http://127.0.0.1:18800/
    ProxyPassReverse / http://127.0.0.1:18800/

    ErrorLog ${APACHE_LOG_DIR}/kevinlin-auth-error.log
    CustomLog ${APACHE_LOG_DIR}/kevinlin-auth-access.log combined

    SSLCertificateFile /etc/letsencrypt/live/server.kevinlin.info/fullchain.pem
    SSLCertificateKeyFile /etc/letsencrypt/live/server.kevinlin.info/privkey.pem
    Include /etc/letsencrypt/options-ssl-apache.conf
</VirtualHost>

This is structured deliberately so that AJAX requests to the authentication endpoint /auth-login will return an HTTP 403 on authentication error (due to a redirect to the /error location which has Deny from all) and HTTP 200 on success. The browser properly takes care of storing the cookie returned by Apache's Set-Cookie header for the domain specified; in the above configuration, all requests to .kevinlin.info domains will have the session cookie header.

Securing a virtual host is as simple as adding a directive under a Location block:

<VirtualHost ...>
	...

	<Location "/">
        AuthFormProvider file
        AuthUserFile "/etc/apache2/.htpasswd"
        AuthType form
        AuthName "SSO"
        AuthFormLoginRequiredLocation "https://auth.kevinlin.info/login?redirect=%{REQUEST_SCHEME}://%{HTTP_HOST}%{REQUEST_URI}"

        Session On
        SessionCookieName session path=/;domain=.kevinlin.info;httponly;secure
        SessionCryptoPassphrase ${APACHE_SESSION_PASSPHRASE}
        SessionMaxAge 86400

        Require valid-user
    </Location>
</VirtualHost>

Deployment

To deploy Apache auth on the default port of 18800,

$ git clone https://github.com/LINKIWI/apache-auth.git
$ cd apache-auth
$ npm install
$ npm run build
$ npm run start

The Apache configuration above proxies an external domain to this local port. You can use monitoring services like pm2 to keep it alive in the background.
