Voice Chatroom (Front-End)

Front-End repo for labs11-intercomApp-FE a/k/a Voice Chatroom.

Table of Contents

• Overview
  • Introduction
  • Mission Statement
• Getting Started
  • Install
    • Dependencies
    • Dev-Dependencies
  • Package Scripts
    • Test App
    • Development App
    • Production App
  • Environment Variables
• PUBLIC Directory
  • HTML file
    • Project Stylesheets Links
    • Project Scripts
• SRC Directory
  • Main JavaScript Files
  • Authorization Components
  • App Components
• Color Palette
• License

Overview

Front-end React application powered by a back-end Node and Express server.
Demo application is deployed to Netlify at https://intercom.netlify.com.

Introduction

Using your phone and headphones, you will have the ability to create voice chatrooms groups, talk directly into your group’s ears, and hear others talk into your ears. You can manage the group, see who is in the group and start up a voice call.

Mission Statement

Our mission is to assist a wide variety of users ranging from those who may be hearing impaired or elderly to anyone who finds themselves as a group having difficulty conversing with others with overbearing background noise. We provide our users to opportunity to easily create and join personal groups and initiate voice chats within those groups to keep a clear communication link with their family and friends. Don't lose your voice, find your Voice Chatroom!

Getting Started

Package Manager: yarn

• Fork and clone this repository
• Change directory into the project directory folder intercom.

Install

yarn install

Dependencies

auth0-js axios bootstrap fuse fuse.js jquery popper.js react react-dom react-loader-spinner react-router-dom react-scripts react-stripe-elements

Dev-Dependencies

jest-dom react-test-renderer react-testing-library

Package Scripts

In the project directory, you can run:

Test App

yarn test

Launches the test runner in the interactive watch mode.

• App testing completed with jest-dom react-test-renderer and react-testing-library.

Development App

yarn start

Runs the app in the development mode.

• Open http://localhost:3000 to view it in the browser.
• The page will reload if you make edits.

Production App

yarn build

Builds the app for production.

• Our production application is deployed to Netlify at https://intercom.netlify.com.

Environment Variables

Environments variables set within local .env file for testing and development. For production variables are set within the Netlify's application Environment Variables settings.

• Local/Production: REACT_APP_HOST REACT_APP_AUTH_CB_DEV REACT_APP_AUTH_CB_PROD REACT_APP_CONTACT_EMAIL
• Auth0: REACT_APP_AUTH_DOMAIN REACT_APP_AUTH_CLIENT_ID REACT_APP_AUTH_AUD
• Stripe: REACT_APP_PK_TEST

PUBLIC Directory

Located within the public folder:

• Application's html file index.html
• CSS stylesheets
• JavaScript files
• Images and logos
• Font packages
• Webtemplate documentation

HTML file

React application rendered through <div id="root"></div> located within the body script of index.html.

Project Stylesheets Links

• Custom CSS: <link rel="stylesheet" href="/css/intercom.css">
• Bootstrap CSS: <link href="/css/bootstrap.min.css" rel="stylesheet">
• Font Awesome: <link href="/font-awesome/css/font-awesome.min.css" rel="stylesheet" type="text/css">
• Material Icons: <link href="https://fonts.googleapis.com/icon?family=Material+Icons" rel="stylesheet">

Project Scripts

• Bootstrap JS: <script src="/js/bootstrap.min.js"></script>
• jQuery JS: <script src="/js/jquery.js"></script>
• Popper JS: <script src="https://cdnjs.cloudflare.com/ajax/libs/popper.js/1.12.9/umd/popper.min.js"></script>
• Stripe: <script src="https://js.stripe.com/v3/"></script>

SRC Directory

Located within the src folder:

• Application's main index.js file
• App, History, Host, and Routes files
• Authorization Components directory
• Custom Components directory
• Default Images directory

Main JavaScript Files

File Name	Purpose
index.js	React application rendered through index.js and renders all routes located within the routes.js file.
routes.js	Renders App.js as main Router and all sub-components as routes within App.
App.js	App.js is this main Router and always renders a Navigations.js sub-component.
history.js	Creates a browser history.
host.js	Exports the process environment's host variable.

Authorization Components

All authorization components are located within the src/Auth directory.
Authorization powered by Auth0.

• When a user logs in or signs up that user's email and password is first verfied by Auth0
• Once verified Auth0 provides a user with an authorization token and provides the App with that user's Auth0 account information
• The account information is then passed to our back-end server to verify or create a user
• Once the user is verified or created a logged in session is set and the user can begin using the App

App Components

All other routes and sub-components are located within the src/components directory which include:

• Navigation Component
• Landing Page View and components
• All App Page Views and components
• All Error and Unauthorized Page Views and components
• All Modal components

Color Palette

License

View License Details
MIT © Intercom App
